The MPA6590 is C/X-band GaAs Power Amplifier IC.
Each chip provides >2W maximum power and operates from a single 6V supply.
Features
- Frequency range: 6.5-9 GHz
- Gain: 25dB
- Output Psat: 33dBm
- Output P1dB: 30dBm
- Bias: 6V, 0.8A
- Total power consumption: 5W
- Size: 4.2mm x 1.8mm
- 100% DC and RF tested on-wafer to ensure performance compliance
Applications
- Point-to-Point Radio
- Communication (5G/6G)
Availability
- Engineering samples available
